You are reading the documentation for ESP-DASH v4.x.x, which is no longer the latest release. View the v5.x.x documentation.Image Card
Display an image from a URL on the ESP-DASH Pro v4 dashboard with the image card.
ESP-DASH Pro feature. This functionality is available only in the commercial edition of ESP-DASH.The image card displays an image loaded from a URL. Use it to show camera snapshots, diagrams or other remotely hosted images on the dashboard.
Constructor
Card image(&dashboard, IMAGE_CARD, "Camera", "lg");Prop
Type
Methods
update()
Sets the URL of the image to display. The card shows no image until a URL is set.
image.update(const char* url);Pass a second argument to change the image size at the same time. Supported sizes are lg and xl:
image.update(const char* url, const char* size);Call dashboard.sendUpdates() afterwards to push the change to connected clients.
Example
#include <Arduino.h>
#if defined(ESP8266)
#include <ESP8266WiFi.h>
#include <ESPAsyncTCP.h>
#elif defined(ESP32)
#include <WiFi.h>
#include <AsyncTCP.h>
#endif
#include <ESPAsyncWebServer.h>
#include <ESPDash.h>
const char* ssid = "YOUR_SSID";
const char* password = "YOUR_PASSWORD";
AsyncWebServer server(80);
ESPDash dashboard(&server);
Card image(&dashboard, IMAGE_CARD, "Camera", "lg");
void setup() {
Serial.begin(115200);
WiFi.mode(WIFI_STA);
WiFi.begin(ssid, password);
if (WiFi.waitForConnectResult() != WL_CONNECTED) {
Serial.println("WiFi connection failed");
return;
}
Serial.print("IP address: ");
Serial.println(WiFi.localIP());
image.update("https://picsum.photos/800/600");
server.begin();
}
void loop() {
// ...
}
